6 THE MANUFACTURE OF CHEMICALS BY ELECTROLYSIS plates from each other. Two holes ho (Fig. 2) in the rim of each electrode communicate so as to form two channels when the unit is made up, and these serve to convey the hydrogen and oxygen from the cells, whilst the lower channels W W , formed in a similar manner, serve to supply the chambers with electrolyte. The channels h and W communicate with the cathode spaces only, whilst o and W connect anode spaces. The FIG. 2. channels W W for supplying water are connected with a main pipe A, and at the other end of the unit the gas channels ho communicate with the washing chambers H and 0. The stopcock a, shown in the diagram of a com- plete Schmidt apparatus (Fig. 3), is for emptying the ap- paratus. The electrolyte recommended is a 10 per cent, potassmm carbonate solution, and is probably preferred to the corresponding sodium salt on account of its freedom from chloride, which exerts a corrosive action upon the iron-work of the apparatus.PDF Image | MANUFACTURE OF CHEMICALS BY ELECTROLYSIS
